Draw-tite
Verify Fitment
Select your vehicle to confirm this part fits.
















DRAW-TITE Class 3 trailer hitches are the perfect mix of style and strength to get you and your equipment wherever you need to go. This DRAW-TITE Class 3 receiver hitch is rated for up to 5,000 lbs. gross trailer weight (GTW) and up to 500 lbs. tongue weight (TW). They are also suitable for use with weight distribution up to 5,000 lbs. weight distribution (WD) and 500 lbs. weight distribution tongue weight (WDTW). DRAW-TITE hitches are designed to provide top towing performance, with solid-all-welded construction and a black powder coat finish to resist rust and corrosion. The Class 3 trailer hitch has a 2 inch square receiver tube opening, allowing you to attach accessories like a bike rack or cargo carrier, or hook up your pop-up, boat trailer, or utility trailer. Includes all the mounting hardware needed for installation and are backed by a nationwide lifetime limited warranty. DRAW-TITE trailer hitches are tested to exceed V-5 and SAE J684 standards. DRAW-TITE: North Americas Favorite Hitch.
| BRAND: | DRAW-TITE |
| PART NUMBER: | 75586 |
| WARRANTY: | LIMITED LIFETIME WARRANTY |
| WEIGHT: | 45 LBS |
| GROSS TOWING WEIGHT: | 5,000 LBS. |
| GROSS TONGUE WEIGHT: | 500 LBS. |
| RECEIVER SIZE: | 2 IN. |
| HITCH CLASS: | III |
| DRILLING REQUIRED: | NO |
| MOUNTING HARDWARE INCLUDED: | YES |
| ATTACHMENT LOCATION: | REAR |
| HITCH VISIBILITY: | VISIBLE |
| CROSS-TUBE TYPE: | SQUARE TUBE |
| BALL MOUNT INCLUDED: | NO |
| COLOR: | BLACK |
| FINISH: | BLACK POWDER COAT OVER E-COAT |
| MATERIAL: | STEEL |
| MOUNTING LOCATION: | VEHICLE FRAME |
| MOUNTING TYPE: | BOLT-ON |
| GROSS TOWING WEIGHT WITH WEIGHT DISTRIBUTION: | 5,000 LBS. |
| GROSS TONGUE WEIGHT WITH WEIGHT DISTRIBUTION: | 500 LBS. |

Draw-Tite has designed custom-fit trailer hitches since 1946 and is one of North America's most widely fitted hitch brands. Receiver hitches use solid all-welded construction and low-profile designs that follow modern vehicle contours, install with minimal bumper cutting or drilling, meet or exceed V5 CSA and SAE J684 standards, and carry a limited lifetime warranty.
Draw-Tite has been leading custom-fit trailer hitch design and engineering since its founding in 1946, and it remains one of the most widely fitted hitch brands in North America. The company's stated approach is straightforward: every hitch is tested rigorously so that it performs well beyond published industry standards, a philosophy it markets as Tested Tough. It sits within the Horizon Global towing group alongside Reese, Fulton, Bulldog, Tekonsha, Bargman and Wesbar.
Custom fit is the defining characteristic. Rather than adapting a universal design, Draw-Tite engineers a trailer hitch for a specific make, model and model year, so it bolts to existing frame locations with minimal bumper cutting or drilling. Low-profile designs follow the rear contours and aerodynamic styling of modern vehicles, which matters more than it once did now that rear fascias are shaped and sensor-equipped. Construction is solid all-welded steel for maximum strength, and every hitch meets or exceeds V5 CSA and SAE J684 standards and is backed by a nationwide limited lifetime warranty.
The range spans receiver sizes and classes to suit different loads, from 1-1/4 inch receivers for bike racks, cargo carriers and light trailers up through 2 inch receivers for heavier towing. Front mount hitches add a receiver at the front of the vehicle for winch mounts, snow plows, spare carriers and precise trailer positioning.
The Hidden Hitch series takes concealment further by mounting behind the vehicle's rear fascia, so the vehicle keeps its factory appearance until a removable receiver is fitted. Each is custom designed per make and model for a no-drill installation that does not compromise ground clearance, rated for up to 3,500 pounds gross trailer weight and 350 pounds tongue weight. Matching plug-and-play wiring completes the towing system.
Lifetime
Draw•Tite® and the Checkered Flag Foundation
1 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2008 - 2013 | Toyota Highlander | Class 3 Trailer Hitch: 5000 lbs 500/5,000 lbs. Weight Carrying (tongue weight/gross trailer weight) 500/5,000 lbs. when used with a Weight Distribution Kit (tongue weight/gross trailer weight) Uses all existing holes. No Drilling required Install Time is 25 minutes Except with 19 in. Spare Tire |
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Toyota Highlander 75586 (Part #DT75586) fits the following vehicles: 2008-2013 Toyota Highlander. Always verify your specific year, make, and model before ordering.
Yes, the Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Toyota Highlander 75586 (Part #DT75586) is designed to fit the 2008-2013 Toyota Highlander.
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Toyota Highlander 75586 (Part #DT75586) fits 2008-2013 Toyota Highlander models. The 2013 model year is the last year covered by this part number. For newer models, check for an updated version.
The Draw-tite Class 3 Trailer Hitch, 2" Square Receiver, Black for Select Toyota Highlander 75586 (Part #DT75586) Refer to the included instructions for installation details. Basic hand tools are typically all you need.
No. This hitch will not fit with a full-size 19" spare tire. If your vehicle is equipped with a full-size 19" spare, you will need to verify alternative fitment options or contact the manufacturer for compatibility.
Yes. Part number 75586 is designed for both Toyota Highlander and Toyota Highlander Hybrid vehicles. However, the hitch will not fit if your vehicle is equipped with a full-size 19" spare tire.
The maximum gross trailer weight is 5000 lb (2270 kg) and the maximum tongue weight is 500 lb (227 kg). However, you must not exceed the lower of the towing vehicle manufacturer's rating or the hitch rating. Always verify your vehicle's towing capacity in your owner's manual.
You will need: a small flat head screwdriver, a Phillips head screwdriver, wrenches in 10mm, 14mm, and 17mm sizes, and a torque wrench. No drill bits are required because the hitch uses existing weldnuts in the vehicle frame.
Fastener kit 75586F includes 6 hex bolts (M10 x 1.25 x 30mm CL10.9) and 6 conical toothed washers (3/8"). These fasteners are installed on both sides of the vehicle frame.
Yes. You must remove the plastic appearance panels that cover the driver's and passenger's side frame rails, and remove the tow hooks from each frame rail. Return all removed panels, hooks, and their fasteners to the vehicle owner.
1. Remove the plastic appearance panels covering the driver's and passenger's side frame rails. 2. Remove the tow hooks from each frame rail. 3. Raise the hitch into position and install the fasteners as shown in the diagram. 4. Tighten all M10 x 1.25 CL10.9 fasteners with a torque wrench to 42 lb-ft (57 N·m).
All M10 x 1.25 CL10.9 fasteners must be tightened to 42 lb-ft (57 N·m) using a torque wrench.
No. This hitch installation does not require drilling. It uses existing weldnuts already present in the vehicle frame.
Check the hitch frequently to ensure all fasteners and the ball are properly tightened. Perform this check regularly during the life of the hitch to maintain safe operation.
If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent the entry of water and exhaust fumes.
A hitch or ball which has been damaged should be removed and replaced immediately. Do not continue to use a damaged hitch.
Observe safety precautions when working beneath a vehicle and wear eye protection. Do not cut access or attachment holes with a torch.
No, this hitch will not fit with a full-size 19" spare tire.
Small flat head screwdriver, Phillips head screwdriver, 10mm/14mm/17mm wrenches, and a torque wrench. No drilling required.
All M10 x 1.25 CL10.9 fasteners must be tightened to 42 lb-ft (57 N·m) with a torque wrench.
Maximum gross trailer weight is 5000 lb (2270 kg) and maximum tongue weight is 500 lb (227 kg), but do not exceed your vehicle manufacturer's towing rating.
Yes, remove plastic appearance panels covering the frame rails and remove the tow hooks from each frame rail.
Check the hitch frequently to ensure all fasteners and the ball are properly tightened. If removed, plug all holes to prevent water and exhaust fume entry.
