CURT
Verify Fitment
Select your vehicle to confirm this part fits.










Trailer hitch weight ratings are limited to vehicle manufacturer's stated capacities
Includes strong, grade-8 installation hardware
Includes strong, grade-8 installation hardware
Warranty: Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Main Body Shape: Square
Receiver Tube Size (Inches): 2-1/2 IN
WC / TW (Pounds): 2,700 LB / 20,000 LB
WD / WDTW (Pounds): 20,000 LB / 2,700 LB
Weight Carrying Capacity (Pounds): 20,000 LB
WC Tongue Weight (Pounds): 2,700 LB
Weight Distribution (Pounds): 20,000 LB
WD Tongue Weight (Pounds): 2,700 LB
Installation Difficulty: Novice
Installation Time Exact (Minutes): 30
In the world of commercial towing, more is expected. A job cannot be completed if the equipment cannot handle the workload. That is why CURT developed the Commercial Duty class 5 trailer hitch. Constructed from steel and engineered for power, these class 5 hitches are designed to complement the towing power of full-size, commercial pickup trucks, including diesels and chassis cabs. They can easily handle a variety of oversize trailers, including toy and car haulers, livestock trailers, dumper trailers, large flatbed trailers, large boat trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component). This particular class 5 hitch features a gross trailer weight capacity of 20,000 lbs. and a tongue weight capacity of 2,700 lbs. It is designed to be a custom trailer hitch for certain years of the Ram 2500 or 3500 and Dodge Ram 1500, 2500 or 3500 (to verify your vehicle compatibility, see application info). All CURT Commercial Duty class 5 hitches feature a 2-1/2" x 2-1/2" receiver tube opening to accept the strongest of ball mounts and towing accessories. They are perfect for mounting standard ball mounts, pintle mounts, tow hooks and weight distribution hitches as well as winch mounts and cargo carriers. CURT class 5 tow hitches are protected by a co-curing of liquid A-coat and carbide black powder coat finish. They also mount with grade-8 hardware, included with each hitch.

CURT offers a variety of high-quality trailer hitches and accessories for select vehicle models. Find the perfect fit for your towing needs at TowUniverse.
CURT, a Lippert brand, offers a complete line of towing products and is the leading manufacturer of custom-fit trailer hitches. We offer the broadest selection of custom-fit hitches, and each one is designed, welded, and coated in Wisconsin.
CURT is also a leader in flat towing products, as well as 5th wheel, gooseneck, and weight distribution hitches, ball mounts, electrical components, cargo solutions, and other towing accessories.
For everything from passenger cars and vans to full-size pickups and SUVs, CURT is 'The First Name in Towing Products®.'
Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
Rediscover "Us" Time | Tested. Proven. Safe. Towing Products
6 compatible vehicles
| Year | Make & Model | Notes |
|---|---|---|
| 2003 | Dodge Ram 1500 | No Drilling Required Installation Time: 30-60 minutes Built in or after November 2002 With or Without Factory Receiver Visibility: Exposed |
| 2004 - 2008 | Dodge Ram 1500 | No Drilling Required Installation Time: 30-60 minutes With or Without Factory Receiver Visibility: Exposed |
| 2003 - 2010 | Dodge Ram 2500 | No Drilling Required Installation Time: 30-60 minutes With or Without Factory Receiver Visibility: Exposed |
| 2003 - 2010 | Dodge Ram 3500 | No Drilling Required Installation Time: 30-60 minutes With or Without Factory Receiver Visibility: Exposed |
| 2011 - 2013 | Ram 2500 | No Drilling Required Installation Time: 30-60 minutes With or Without Factory Receiver Visibility: Exposed |
| 2011 - 2013 | Ram 3500 | No Drilling Required Installation Time: 30-60 minutes Visibility: Exposed With or Without Factory Receiver |
The CURT Commercial Duty Class 5 Hitch, 2-1/2", Select Dodge, Ram 1500, 2500, 3500 Trailer Hitch (Part #BKDK15809) fits the following vehicles: 2003-2008 Dodge Ram 1500; 2003-2010 Dodge Ram 2500; 2003-2010 Dodge Ram 3500; 2011-2013 Ram 2500; 2011-2013 Ram 3500. Always verify your specific year, make, and model before ordering.
Yes, the CURT Commercial Duty Class 5 Hitch, 2-1/2", Select Dodge, Ram 1500, 2500, 3500 Trailer Hitch (Part #BKDK15809) is designed to fit the 2003-2008 Dodge Ram 1500.
The CURT Commercial Duty Class 5 Hitch, 2-1/2", Select Dodge, Ram 1500, 2500, 3500 Trailer Hitch (Part #BKDK15809) fits 2003-2008 Dodge Ram 1500 models. The 2013 model year is the last year covered by this part number. For newer models, check for an updated version.
The CURT Commercial Duty Class 5 Hitch, 2-1/2", Select Dodge, Ram 1500, 2500, 3500 Trailer Hitch (Part #BKDK15809) Drilling is not required for installation. Typical installation time is 30-60 minutes. Basic hand tools are typically all you need.
Yes, part 15809 fits 03-08 Dodge Ram 1500 models built after November 2002, with or without an OEM receiver. It will not fit 1500 models built before November 2002.
Yes, part 15809 fits 03-current Dodge Ram 2500 and 3500 models, with or without an OEM receiver.
Yes, part 15809 can be installed on vehicles with a factory hitch. However, you may need to loosen the factory hitch and bumper beam and push it toward the rear of the vehicle to create additional space for the Curt hitch.
Yes, part 15809 fits both long bed and short bed models. The mounting hole alignment differs by bed length: long bed vehicles use the front-most hole on the hitch side plates, while short bed vehicles use the middle hole.
You will need a socket wrench, torque wrench, 8 inch socket extension, 13/16" socket, and 7/8" socket. No drilling is required.
The kit includes: 2× 9/16-12 UNC grade 8 hex carriage bolts (10-10500), 2× 9/16" fishwire, 2× 9/16" flat washers (30-00202), 6× 9/16-12 UNC grade 8 serrated flange nuts (20-00104), 4× 9/16-12 UNC 1-3/4" grade 8 carriage bolts (10-10328), 2× .313 × 2.13 × 2.13" spacers with 9/16" square hole (CM-SP68), 2× .313 × 1.50 × 3.00" spacers with 9/16" square hole (CM-SP74), and 6× .188 × 1.25 × 1.50" spacers with round hole (CM-SP8).
Professional installation takes approximately 60 minutes. DIY installation by a novice takes approximately 80 minutes.
Hole alignment depends on vehicle bed length. Long bed vehicles use the front-most hole on the hitch side plates. Short bed vehicles use the middle hole on the hitch side plates.
CM-SP74 spacers (.313 × 1.50 × 3.00" with 9/16" square hole) are slid through the frame rail ends and aligned with the front mounting holes. CM-SP68 spacers (.313 × 2.13 × 2.13" with 9/16" square hole) are slid through the frame rail ends and aligned with the rear mounting holes. Both spacers ensure proper alignment and spacing during installation.
Fishwire is used to thread 9/16" carriage bolts through the access holes in the side of the frame rails and through the spacers. This technique allows the bolts to be inserted and positioned before final tightening. The manual references a fishwire technique diagram for detailed guidance.
Dodge Ram 1500 models use the bottom slot in the hitch side plate when aligning with vehicle tow loops.
Dodge Ram 2500 and 3500 models use the top slot in the hitch side plate when aligning with vehicle tow loops.
CM-SP8 spacers (.188 × 1.25 × 1.50" with round hole) are installed between the tow loops and hitch side plates to prevent the tow loops from pulling into the hitch when the hex bolts are tightened. Install enough spacers as needed to maintain proper clearance.
All 9/16" hardware on the Curt 15809 hitch must be torqued to 150 lb-ft. This includes the carriage bolts and hex bolts. Torque the carriage bolts first (Step 7), then torque the remaining 9/16" hardware after installing the hex bolts and spacers (Step 11).
The manual specifies that you must not exceed your vehicle manufacturer's recommended towing capacity. The manual does not provide the hitch's specific load capacity values, as those fields are blank in the document. Contact Curt Manufacturing technical support at 1-877-287-8634 for the complete capacity specifications.
After installation, periodically check that all fasteners are tight and that all structural components are sound. This maintenance is essential for safe operation.
Curt Manufacturing warrants this product to be free of defects in material and workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt will repair or replace it at their option when returned prepaid with proof of purchase. Alteration, misuse, or improper installation voids the warranty. Curt's liability is limited to repair or replacement and excludes liability for incidental or consequential loss or damage.
Yes, if you have a 03-current Ram 2500/3500 or a 03-08 Ram 1500 built after November 2002. It fits with or without a factory hitch.
No, drilling is not required. The hitch uses existing frame rail holes and access holes.
You need a socket wrench, torque wrench, 8 inch socket extension, 13/16" socket, and 7/8" socket.
Torque all 9/16" hardware to 150 lb-ft.
Professional installation takes 60 minutes; DIY installation takes approximately 80 minutes.
Yes. Long bed trucks use the front-most hole; short bed trucks use the middle hole on the hitch side plates.
